B1017/16-Machine Reamer

B1017/16-Machine Reamer

Dormer

$45.57
(No reviews yet) Write a Review
SKU:
DOP-5986711
UPC:
7320760181249
Product measurement standard:
Inch
Cutting diameter - millimeter (DC):
11.11
Cutting diameter - inch (DC):
0.4375
Cutting diameter - fractional inch (DC):
7/16
Length chip flute - millimeter (LCF):
71
Overall length - millimeter (OAL):
151
Connection size code machine side (CZC MS):
MK 1
Overall length - inch (OAL):
5.9449
Material code (BMC):
HSS-E
Basic standard group (BSG):
BS 328
Coating:
Bright/ST
Shank:
Morse Taper Shank
Flute count (NOF):
6
Achievable hole tolerance (TCHA):
H7
Hand (Cutting direction):
Right
Country of origin:
Germany
Gross weight - grams:
92.7
Box width millimeter:
17.74
Box length millimeter:
152
Box height millimeter:
16.81
Box width inches:
0.698
Box length inches:
5.984
Box height inches:
0.662
Product name ISO:
B1017/16
Ordering code ANSI:
B1017/16
EAN number:
7320760181249
EDP number:
0181249
Package Quantity:
1
Adding to cart… The item has been added

Machine reamer with left hand slow spiral flutes and a Morse taper shank, diameter 11.11mm (7/16") with an overall length of 151mm and a flute length of 71mm, according to BS 328 standard for reaming precise holes within H7 tolerance, cobalt based HSS-E with bright-steam tempered finish for machining free machining, plain carbon and alloy steel, grey and malleable cast-iron, wrought and cast aluminium and copper or copper alloys

Applications:

P - Steel and cast steel(steels with alloy content ? 10% and a hardness of < 45HRC) - Primary use

M - Stainless steel(corrosion resistant steels with ? 11% chromium content) - Possible use

K - Cast Iron(castings of iron and carbon alloys with > 2% carbon content) - Primary use

N - Non-ferrous metals(metals including alloys without an appreciable amount of iron) - Primary use

For additional details please check the Manufacturer's site:

B1017/16
