EX411.1/4-G(BSP) Machine Tap Spiral Flute 45°

Dormer

(No reviews yet) Write a Review

Write a Review

Close ×

Dormer

EX411.1/4-G(BSP) Machine Tap Spiral Flute 45°

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name Required

Email Required

Review Subject Required

Comments Required

SKU:

DOP-5973838

UPC:

7320760168745

Product measurement standard:

Inch

Connection diameter - millimeter (DCON MS):

32

Overall length - millimeter (OAL):

170

Thread diameter size (TDZ):

1.1/4

Threading length - millimeter (THL):

22

Thread diameter - inch (TD):

1.65

Thread diameter - millimeter (TD):

41.91

Threads per inch (TPI):

11

Premachined hole diameter - millimeter (PHD):

39.5

Connection diameter - inch (DCON MS):

1.2598

Overall length - inch (OAL):

6.6929

Clamping Length - millimeter (LSC):

27

Clamping width - millimeter (WSC):

24

Threading length - inch (THL):

0.8661

Clamping Length - inch (LCS):

1.063

Clamping width - inch (WSC):

0.9449

Premachined hole diameter - inch (PHD):

1.5551

Material code (BMC):

HSS-E

Basic standard group (BSG):

DIN 5156

Coating:

Steam Tempered

Shank:

Cylindrical shank with Square

Usable length (ULDR):

2.5

Flute count (NOF):

4

Tap Application:

Blind Hole

Tap chamfer style (TCS):

C 2 - 3

Thread form (THFT):

G - British standard pipe fastening - G series

Flute Geometry (FDC):

Spiral Flute Geometry

Flute helix angle (FHA):

45

Hand (Cutting direction):

Right

Country of origin:

India

Gross weight - grams:

974.3

Box width millimeter:

45

Box length millimeter:

175

Box height millimeter:

45

Box width inches:

1.772

Box length inches:

6.89

Box height inches:

1.772

Product name ISO:

EX411.1/4

Ordering code ANSI:

EX411.1/4

EAN number:

7320760168745

EDP number:

0168745

Package Quantity:

1
